1/4 x 1/4 x 1/4 Inch Cube Magnet | B444B N42 Magnets

For customized services, please get in touch with us. We will provide pricing and availability within 24 hours.

1/4 x 1/4 x 1/4 Inch Cube Magnet | B444B N42 Magnets

Additional information

Description:

Dimensions: 1/4″ x 1/4″ x 1/4″ thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Black Ni (Black Nickel)
Magnetization Direction: Thru Thickness
Weight: 0.0677 oz. (1.92 g)
Pull Force, Case 1: 4.25 lbs
Pull Force, Case 2: 5.20 lbs
Surface Field: 5754 Gauss
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

Applications:

Here we have our popular 1/4″ cubes with a sleek black nickel finish. The black nickel plating gives these magnets a shiny, charcoal-colored appearance. They are identical to the B444, with just a different color.

This size is also available in grade N42 with our standard Nickel plating under part number B444, in grade N52 under part number B444-N52, and with a 1/16″ hole through the center as part number B444-1.

Note: Our “Black Nickel” plating is achieved by adding a special tint during the nickel plating process. While the finish is not black, the magnets have a grey, charcoal, or gunmetal appearance. Due to this unique process, slight color variations may occur between orders.
