1/2 x 1/4 x 1/32 Inch Bar Magnet | B8401 N42 Magnets

For customized services, please get in touch with us. We will provide pricing and availability within 24 hours.

1/2 x 1/4 x 1/32 Inch Bar Magnet | B8401 N42 Magnets

Additional information

Description:

Dimensions: 1/2″ x 1/4″ x 1/32″ thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Ni (Nickel)
Magnetization Direction: Thru Thickness
Weight: 0.017 oz. (0.480 g)
Pull Force, Case 1: 0.91 lbs
Pull Force, Case 2: 8.47 lbs
Surface Field: 1152 Gauss
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

Applications:

These blocks are small, thin, and incredibly versatile, making them ideal for a wide range of home, office, and industrial applications. Whether you’re working on a DIY project, organizing tools, or prototyping a product, these handy magnets offer strong holding power in a compact size.
