1/2 x 1/4 x 1/10 Inch Bar Magnet | B84H1 N42 Magnets

For customized services, please get in touch with us. We will provide pricing and availability within 24 hours.

1/2 x 1/4 x 1/10 Inch Bar Magnet | B84H1 N42 Magnets

Additional information

Description:

Dimensions: 1/2″ x 1/4″ x 1/10″ thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Ni (Nickel)
Magnetization Direction: Thru Thickness
Weight: 0.0542oz. (1.537 g)
Pull Force, Case 1: 3.40 lbs
Pull Force, Case 2: 10.27 lbs
Surface Field: 3192 Gauss
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

Applications:

These blocks are small, thin, and highly practical, making them perfect for a wide range of home and industrial applications. Their compact size allows them to fit into tight spaces while still providing strong magnetic holding power. Ideal for crafts, closures, fixtures, and countless other uses where a low-profile magnet is needed.
