1/8 x 3/32 Inch Disc Magnet | D203-N42 Magnets
INQUIRY

For customized services, please get in touch with us. We will provide pricing and availability within 24 hours.

1/8 x 3/32 Inch Disc Magnet | D203-N42 Magnets

Categories , ,

Additional information

Facebook
Twitter
LinkedIn

Description:

  • Dimensions: 1/8″ dia. x 3/32″ thick
  • Tolerances: ±0.004″ x ±0.004″
  • Material: NdFeB, Grade N42
  • Plating/Coating: Ni-Cu-Ni (Nickel)
  • Magnetization Direction: Axial (Poles on Flat Ends)
  • Weight: 0.00499 oz. (0.141 g)
  • Pull Force, Case 1: 0.60 lbs
  • Pull Force, Case 2: 0.85 lbs
  • Surface Field: 5496 Gauss
  • Max Operating Temp: 176ºF (80ºC)
  • Brmax: 13,200 Gauss
  • BHmax: 42 MGOe

Applications:

These small magnets may be tiny in size, but they pack impressive strength, making them suitable for a wide variety of applications where space is limited but holding power is essential.
