1/10 x 1/32 Inch Disc Magnet | DH101-N42 Magnets

For customized services, please get in touch with us. We will provide pricing and availability within 24 hours.

1/10 x 1/32 Inch Disc Magnet | DH101-N42 Magnets

Additional information

Description:

Dimensions: 1/10″ dia. x 1/32″ thick
Tolerances: ±0.004″ x ±0.004″
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Ni (Nickel)
Magnetization Direction: Axial (Poles on Flat Ends)
Weight: 0.00106 oz. (0.0302 g)
Pull Force, Case 1: 0.14 lbs
Pull Force, Case 2: 0.54 lbs
Surface Field: 3498 Gauss
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

Applications:

The DH101 magnets are among the smallest discs we offer—and they’re incredibly popular! Their compact size makes them ideal for modern electronics, sensors, and medical devices, where space is at a premium. But they’re not just for tech: hobbyists, crafters, and science enthusiasts love them for projects and experiments. Plus, this hard-to-find size comes at an unbeatable price!
