1/8 od x 1/16 id x 1/16 inch thick Ring Magnets | R211 Magnet

For customized services, please get in touch with us. We will provide pricing and availability within 24 hours.

1/8 od x 1/16 id x 1/16 inch thick Ring Magnets | R211 Magnet

Categories Neodymium Magnets, Neodymium Ring Magnets, Permanent Magnets

Additional information

Description:

Dimensions: 1/8″ od x 1/16″ id x 1/16″ thick
Tolerances: ±0.004″ x ±0.004″ x ±0.004″
Material: NdFeB, Grade N42
Plating/Coating: Ni-Cu-Ni (Nickel)
Magnetization Direction: Axial (Poles on Flat Ends)
Weight: 0.00249 oz. (.0707 g)
Pull Force, Case 1: 0.36 lbs
Pull Force, Case 2: 0.64 lbs
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

Applications:

These tiny rings are the smallest rings we can provide! Use them in small arts and crafts, or wherever you need a small ring!
