2 Inch Sphere Magnet | SY0 N42 Magnets

For customized services, please get in touch with us. We will provide pricing and availability within 24 hours.

2 Inch Sphere Magnet | SY0 N42 Magnets

Additional information

Description:

Dimensions: 2″ diameter
Tolerances: ±0.004″
Material: NdFeB, Grade N42
Plating/Coating: NiCuNi (Nickel)
Magnetization Direction: Axially Magnetized (Poles at 2 points, 180° opposite one another)
Weight: 18.16 oz (515 g)
Pull Force, Case 1: 103.3 lbs
Pull Force, Case 2: 114.0 lbs
Surface Field: 8815 Gauss
Max Operating Temp: 176ºF (80ºC)
Brmax: 13,200 Gauss
BHmax: 42 MGOe

Applications:

These 2″ sphere magnets are incredibly strong—among the most powerful we offer. The magnetic fields of sphere magnets are highly concentrated at the poles, even more so than disc or block magnets.

Extreme caution is required when handling these magnets. Due to their size and strength, they can cause serious injury if mishandled.

You must read and understand our [Neodymium Magnet Safety Page] before ordering. By purchasing, you acknowledge and agree to our Terms and Conditions. THESE MAGNETS ARE DANGEROUS.
